With safety switch
Pit ladder type A, 3,60 m EN 81-20
Order no.: 0311360010
| Materials / corrosion protection: | extruded aluminium profile |
| Weight (kg): | 7,30 |
| Exterior ladder width (mm): | 350 |
| Interior ladder width (mm): | 300 |
| Number of rungs: | 12 |
| Ladder length (m): | 3,60 |
| Ladder application: | stationary and inclinable |
| DIN EN 81-20/50 compliant: | yes |
| Stile dimension (mm): | 50 x 25 |
| Design-related angle of inclination alpha: | 74° |
| Max. pit depth with angle of inclination =alpha (m): | 2,350 |
| Rung dimension/rung depth (mm): | 29 x 29 |
Description:
with galvanised steel suspension and electrical safety switch
Suitable accessories
Ladder suspension fitting with 3-edge lock
Ladder suspension fitting for the use of a padlock
